Description
HH Electronics 6.5” 2 Way Ceiling Speaker - White is the TNi-C6, a 6.5-inch 2-way coaxial ceiling speaker for 70V/100V or 8 ohm low impedance lines, rated at 55W AES and 220W peak. A 6-position power tap selector sits under the front steel grille so output can be adjusted after installation.
Specifications
| SKU | 27017 |
|---|---|
| Model | TNi-C6 |
| 100V power options | 40W, 20W, 10W |
| 70V power options | 20W, 10W, 5W |
| Power tap selector | 6-position, under the front steel grille |
| Frequency response (-10) | 75Hz > 20kHz |
| Frequency response (-3) | 85Hz - 16kHz |
| LF driver | 6.5 inch, paper cone |
| HF driver | 1.5 inch neodymium |
| Low nominal system impedance | 8 ohm |
| Power | 55W AES, 220W peak |
| Max SPL (1M) (Peak) | 113 dB SPL |
| Sensitivity (1W/1M) | 90 dB SPL |
| Nominal coverage | 120° conical |
| Input connector | Push spring connectors |
| Mounting points | 4x dog ear brackets |
| Main construction material | ABS plastic |
| Grille | 1.5mm circular mesh steel |
| Finish | White |
Measurements
| Mounting depth | 176mm (6.9”) |
|---|---|
| Installation grip range | 4 - 20mm |
| Cutout | 235mm (9.3”) |
| Outside diameter | 260mm (10.2”) |
| Weight | 2.1 kg (4.6 lb) |
Common questions
Does the HH Electronics TNi-C6 work on 70V and 100V systems?
Yes. The HH Electronics TNi-C6 has 100V taps of 40W, 20W and 10W, 70V taps of 20W, 10W and 5W, and also runs on an 8 ohm low impedance line.
What size hole does the HH Electronics TNi-C6 need?
The HH Electronics TNi-C6 needs a 235mm (9.3”) cutout, a mounting depth of 176mm (6.9”), and fits ceilings with an installation grip range of 4 - 20mm.
What drivers are in the HH Electronics TNi-C6?
The HH Electronics TNi-C6 has a 6.5 inch paper cone LF driver and a 1.5 inch neodymium HF driver, with 120° conical coverage.
How is the HH Electronics TNi-C6 installed?
The HH Electronics TNi-C6 mounts with 4 dog ear brackets and wires up with push spring connectors.
How loud is the HH Electronics TNi-C6?
The HH Electronics TNi-C6 has a sensitivity of 90 dB SPL (1W/1M) and a max SPL of 113 dB SPL (1M, peak).
