Description
Warm Audio WA273-EQ Dual Channel British Mic Preamp + EQ is a dual-channel '73-style British mic preamp with a 3-band EQ and highpass, 80 dB of gain and a fully discrete, Carnhill transformer-balanced signal path. It works with condenser, dynamic and ribbon microphones.
Specifications
| SKU | HL00323647 |
|---|---|
| Model | WA273-EQ |
| Type | Dual-channel '73-style mic preamp with EQ |
| Class | A solid state |
| Number of channels | 2 |
| Gain | 80 dB |
| Signal path | Fully discrete, Carnhill transformer balanced |
| Phantom power | Yes |
| Polarity switch | Yes |
| EQ low | 35 Hz, 60 Hz, 110 Hz, 220 Hz |
| EQ mid | 360 Hz, 700 Hz, 1600 Hz, 3200 Hz, 4800 Hz, 7200 Hz |
| EQ high | 10 kHz, 12 kHz, 16 kHz |
| Highpass | Yes |
| Analog inputs | 4 x XLR (mic); 2 x 1/4” (Hi-Z); 2 x 1/4” (line) |
| Analog outputs | 2 x XLR; 2 x 1/4” |
| Channel inserts | Yes |
| Frequency response | 20 Hz - 20 kHz (±0.5 dB) |
| Power source | Standard IEC AC cable |
Measurements
| Rack spaces | 2U |
|---|---|
| Width | 19” |
Common questions
How many channels does the Warm Audio WA273-EQ have?
The Warm Audio WA273-EQ has 2 channels, each with a preamp and EQ.
What EQ frequencies does the Warm Audio WA273-EQ have?
The Warm Audio WA273-EQ EQ has low bands at 35, 60, 110 and 220 Hz, mid bands from 360 Hz to 7200 Hz, high bands at 10, 12 and 16 kHz, plus a highpass.
How much gain does the Warm Audio WA273-EQ have?
The Warm Audio WA273-EQ has 80 dB of gain through a fully discrete, Carnhill transformer-balanced signal path.
What inputs and outputs does the Warm Audio WA273-EQ have?
The Warm Audio WA273-EQ has 4 XLR mic inputs, 2 1/4” Hi-Z inputs, 2 1/4” line inputs, 2 XLR outputs, 2 1/4” outputs and channel inserts.
How much rack space does the Warm Audio WA273-EQ take?
The Warm Audio WA273-EQ takes 2U of rack space at 19” wide.
What microphones work with the Warm Audio WA273-EQ?
The Warm Audio WA273-EQ works with condenser, dynamic and ribbon microphones and has phantom power and a polarity switch.
