Description
Warm Audio Mutation Phasor II Electro-Optical Phase-Shifting Pedal is an electro-optical phase-shifting pedal with rate, depth and feedback controls and a phasing rate of 0.1 Hz to 18 Hz. It uses RC4558P op-amps and buffered bypass.
Specifications
| SKU | HL01256636 |
|---|---|
| Type | Electro-optical phase-shifting pedal |
| Controls | Rate, depth and feedback |
| Components | RC4558P op-amps, various vintage-style diodes and hand-selected film capacitors and carbon resistors |
| Bypass | Buffered bypass |
| Power | 9V battery or external 9V regulated DC adapter (center-negative) |
| Phasing rate | 0.1 Hz - 18 Hz |
| Frequency response | 20 Hz - 20 kHz |
| Min feedback | 4V RMS, 11.2V peak-to-peak |
| Max feedback | 2V RMS, 5.6V peak-to-peak |
| Signal-to-noise ratio | 86 dB below 2V input |
| Current draw | 150 mA |
Common questions
What controls does the Warm Audio Mutation Phasor II have?
The Warm Audio Mutation Phasor II has rate, depth and feedback controls.
How fast can the Warm Audio Mutation Phasor II phase?
The Warm Audio Mutation Phasor II has a phasing rate of 0.1 Hz to 18 Hz and a frequency response of 20 Hz to 20 kHz.
How do I power the Warm Audio Mutation Phasor II?
The Warm Audio Mutation Phasor II runs on a 9V battery or an external 9V regulated, center-negative DC adapter, with a current draw of 150 mA.
Is the Warm Audio Mutation Phasor II true bypass?
No. The Warm Audio Mutation Phasor II uses buffered bypass.
What op-amps are in the Warm Audio Mutation Phasor II?
The Warm Audio Mutation Phasor II uses RC4558P op-amps with vintage-style diodes, hand-selected film capacitors and carbon resistors.
