Description
PreSonus AudioBox USB 96 25th Anniversary Edition Interface is a USB 2.0 bus-powered audio interface with two combo mic/instrument inputs, balanced line outputs, MIDI I/O and a steel chassis. It is USB class-compliant with no special drivers needed, and comes with Studio One Artist and the Studio Magic Suite, for singer/songwriters, podcasters and collaborations.
Specifications
| SKU | AUDIOBOX USB 96 25TH |
|---|---|
| Model | AudioBox USB 96 25th Anniversary Edition |
| Voltage | USB Bus Powered |
| Inputs | Two - Combo Mic/Instrument Inputs (XLR Female Balanced, 1/4” TS Female Unbalanced) |
| Headphone jack | 1/4” TRS Active Stereo |
| Line out | Two - 1/4” Balanced (Left and Right) |
| Connection type | USB 2.0 Bus-Powered |
| MIDI I/O | Dual 5-Pin Female DIN |
| Chassis | Steel |
| Compatibility | USB class-compliant (no special drivers); Apple Silicon-based Macs, iOS and iPadOS devices; software for macOS, Windows, iOS and iPadOS |
| Mic preamp THD+N | < 0.008% (Unweighted, 1 kHz @ +4 dBu Output, Unity Gain) |
| Mic preamp signal to noise ratio | > 95 dB (Unity Gain, Ref. = +4 dBu, 20 Hz to 22kHz) |
| Common mode rejection ratio | > 45 dB (1 kHz, 55 dB Gain) |
| Gain control range | 0 dB to 35 dB (±1 dB) |
| Mic preamp maximum input level | -3 dB (Unity Gain, 1 kHz @0.5% THD+N) |
| Phantom power | +48 VDC (±2 VDC) |
| Mic preamp frequency response | 20 Hz to 20 kHz (±3.0 dB) |
| Mic preamp input impedance | 1200Ω (Balanced) |
| Main and line outputs output impedance | 51Ω |
| Headphone outputs maximum output | 60 mW/Channel @ 60Ω Load |
| Headphone frequency response | 20 Hz to 30 kHz (±1.0 dB) |
| ADC dynamic range | 105 dB (A-Weighted, 48 kHz Sample Rate) |
| DAC dynamic range | 105 dB (A-Weighted, 48 kHz Sample Rate) |
| Bit depth | 24 |
| Supported sample rates | 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz |
What is included
- PreSonus AudioBox USB 96 25th Anniversary Edition interface
- Studio One Artist and Studio Magic Suite software bundle
Common questions
How many inputs does the PreSonus AudioBox USB 96 have?
The PreSonus AudioBox USB 96 25th Anniversary Edition has two combo mic/instrument inputs (XLR balanced and 1/4” TS unbalanced).
Does the PreSonus AudioBox USB 96 need a power supply?
No. The PreSonus AudioBox USB 96 25th Anniversary Edition is USB 2.0 bus powered.
Does the PreSonus AudioBox USB 96 work with iPad and Apple Silicon Macs?
Yes. The PreSonus AudioBox USB 96 25th Anniversary Edition is USB class-compliant with no special drivers and works with Apple Silicon-based Macs, iOS and iPadOS devices.
What software comes with the PreSonus AudioBox USB 96?
The PreSonus AudioBox USB 96 25th Anniversary Edition includes the Studio One Artist and Studio Magic Suite bundle.
What sample rates does the PreSonus AudioBox USB 96 support?
The PreSonus AudioBox USB 96 25th Anniversary Edition records at 24-bit and supports 44.1 kHz, 48 kHz, 88.2 kHz and 96 kHz.
Does the PreSonus AudioBox USB 96 have phantom power and MIDI?
Yes. The PreSonus AudioBox USB 96 25th Anniversary Edition has +48 VDC phantom power and dual 5-pin MIDI I/O.
