On-Stage DB500: Seamless High-to-Low Impedance Conversion for Clear Sound
The On-Stage DB500 Passive DI Box seamlessly converts high-impedance 1/4" inputs to low-impedance XLR outputs. Crafted with precision, its high-quality transformer ensures minimal distortion and a clean, isolated signal path. You can send your output signal over long cable runs to mixers or PA systems without loss of frequency.
Featuring a rugged metal construction, the DB500 guarantees durability for prolonged use in any setting. Its passive circuitry eliminates the need for power or batteries, offering convenience and reliability. With a -20 dB or -40 dB pad switch, clipping is prevented, while the ground-lift switch defeats ground-loop hum.
Versatile and Compact: On-Stage DB500 - Your Go-To Solution for Pro Audio Setup
Ideal for acoustic guitars, bass guitars, keyboards, and more, this DI box is a versatile solution for professional audio setups. Compact and lightweight, it measures (W)4.75" x (H)1.375" x (D)2.875" and weighs just 0.5 lbs.
FEATURES:
- Converts a high-impedance (1.4") input to a balanced, low-impedance (XLR) output
- High-quality transformer for low distortion and an isolated signal path
- Output signal can be sent via a long cable to a mixer or PA system without frequency loss
- Passive circuit does not require a power supply or batteries
- Application: Acoustic guitars, bass guitars, key boards and more
- Construction: Metal
- Dimensions: (W)4.75" x (H)1.375" x (D)2.875"
- Input Impedance: 350K Ohms
- Inputs: 1/4"
- Output: XLR
- Output Impedance: 80 Ohms
- Pad: 20dB, 40dB, Ground Lift: Yes
- Power: Passive/not required
- Weight: 0.5 lbs
SKU: DB500
