Description
Stagg SSM30 Condenser Microphone is a cardioid condenser microphone for vocal and instrumental recording, with a 34-mm pressure gradient transducer capsule, a 20 Hz to 18 kHz frequency response and a 12 to 52 V power supply.
Specifications
| SKU | 25317 |
|---|---|
| Model | SSM30 |
| Uses | Vocal and instrumental |
| Capsule | 34-mm pressure gradient transducer |
| Polar pattern | Cardioid |
| Sensitivity | - 34 dB +/- 2 dB (0 dB = 1 V / Pa at 1 kHz) |
| Frequency response | 20 Hz to 18 kHz |
| Output impedance | 100 ohms +/- 30 % (at 1 kHz) |
| Maximum sound pressure level | 132 dB (at 1 kHz ≤ 1 % THD) |
| Signal to noise ratio | 80 dB |
| Power supply | 12 to 52 V |
Measurements
| Dimensions | 50.5 x 152 mm (2 x 6”) |
|---|---|
| Weight | 245 g (0.5 lb) |
Common questions
What type of microphone is the Stagg SSM30?
The Stagg SSM30 is a condenser microphone with a 34-mm pressure gradient transducer capsule and a cardioid polar pattern, for vocal and instrumental use.
How is the Stagg SSM30 powered?
The Stagg SSM30 takes a 12 to 52 V power supply.
What is the frequency response of the Stagg SSM30?
The Stagg SSM30 has a frequency response of 20 Hz to 18 kHz and a sensitivity of - 34 dB +/- 2 dB.
What are the noise and SPL specs of the Stagg SSM30?
The Stagg SSM30 has a maximum sound pressure level of 132 dB at 1 kHz with 1 % THD or less, a signal to noise ratio of 80 dB and an output impedance of 100 ohms.
How big is the Stagg SSM30?
The Stagg SSM30 measures 50.5 x 152 mm (2 x 6”) and weighs 245 g (0.5 lb).
